Technical Parameters:
Chassis material | SUS 304 stainless steel |
Relative humidity | ≤95%, non-condensing |
Working environment | indoor, outdoor |
Size | 1400L*160W*1000H（MM） |
Passage width | 600-900 mm |
Passing direction | single direction/ bi-direction |
Door opening and closing time | 0.8-1 seconds adjustable |
Traffic speed | 30 people/minute |
Standard product functions and features:
1. It has the function of fault self-check and alarm prompt, with voice broadcast function, which is convenient for users to maintain and use.
2. Through the built-in small button on the main control board, the operating status of the programmable device is equipped with a visual digital tube screen.
3. This type of speed gate turnstile is a brand-new clutch brushless motor rotating movement.
4. Digitally controlled hall code disc limit, accurate and efficient.
5. Illegal intrusion, tailgating alarm, reverse intrusion gate is automatically closed,
6. Anti-collision function, when the gate opening signal is not received, swing the swing arm at an angle of 10 degrees, and the swing arm will automatically lock.
7. The swing arm can be adjusted synchronously (for the case of double swing).
8. It has an automatic reset function. After the gate is opened, if the pedestrian does not pass within the specified time, the system will automatically cancel the pass permission of the pedestrian. The reset time is adjustable from 1S to 60S (the default time of the system is 10S). The rear channel is automatically opened (according to fire protection requirements), and the power-on channel is automatically closed.
