Technical Parameters:
Chassis material | SUS 304 stainless steel |
Relative humidity | ≤95%, non-condensing |
Working environment | indoor, outdoor |
Size | 1400L*310W*980H（MM） |
Passage width | 550mm |
Passing direction | single direction/ bi-direction |
Door opening and closing time | 0.8-1 seconds adjustable |
Traffic speed | 40 people/minute |
Standard product functions and features:
1. It has fault self checking and alarm prompt functions, making it convenient for users to maintain and use.
2. The operating status of programmable devices can be accessed through the built-in small keypad on the main control board.
3. Current anti pinch and infrared induction anti pinch functions. When the gate plate encounters resistance during the reset process, it will bounce back and automatically stop working within the specified time. It will reset again after a default delay (until reset), with a small force (≤ 2Kg).
4. Illegal intrusion, tailgating alarm, reverse intrusion gate automatically closes and voice alarm.
5. The anti-collision function automatically locks the gate when no opening signal is received.
6. The telescopic arm is synchronously adjustable (for double swing situations).
7. It has an automatic reset function. After the gate is opened, if no one passes through within the specified time, the system will automatically cancel the pedestrian's permission to pass. The reset time is adjustable from 1 second to 60 seconds (the system default time is 10 seconds). After power failure, the channel will automatically open (in accordance with fire safety requirements), and the power on channel will automatically close.
8. Infrared sensing reset, infrared sensing anti pinch function (optional 6 or 8 pairs of infrared).
9. It can be integrated with various devices such as access control systems, consumer systems, electronic ticket systems, biometric systems, electrostatic testers, etc.
