How to install tripod turnstiles?

Installing a tripod turnstile involves several steps, including site preparation, assembly, electrical connections (if motorized), and testing. Below is a step-by-step guide:

Tools & Materials Needed

- Tripod turnstile unit

- Foundation bolts/anchor bolts

- Concrete (if new foundation is required)

- Power drill & wrench set

- Level

- Measuring tape

- Screwdrivers

- Electrical wiring tools (if applicable)

- User manual (specific to your model)

Installation Steps

1. Site Preparation

- Ensure the installation area is flat, solid, and free from obstructions.

- If installing on a new concrete base:

  - Dig a foundation pit (check dimensions per the manual).

  - Pour concrete and embed anchor bolts in the correct positions.

  - Allow concrete to cure (typically 24–48 hours).

2. Mounting the Turnstile Base

- Place the turnstile over the anchor bolts.

- Secure the base using nuts and washers.

- Use a level to ensure the turnstile is perfectly vertical.

3. Installing the Tripod Arms

- Attach the rotating tripod arms to the central spindle.

- Tighten screws/bolts securely.

- Ensure smooth rotation without wobbling.

4. Electrical Connections (For Motorized Models)

- Connect power supply (typically AC 110V/220V or 24V DC).

- Wire the control board (follow the manufacturer’s diagram).

- Connect access control devices (card reader, biometric scanner, etc.) if applicable.

- Test the motorized function before finalizing installation.

5. Testing & Adjustment

- Manually rotate the arms to check smooth movement.

- Test locking mechanism (should stop unauthorized passage).

- For motorized models, verify:

  - Unlocking (when access is granted).

  - Alarm (if forced rotation is attempted).

  - Auto-reset (if applicable).

6. Final Fixing & Maintenance Tips.

- Double-check all bolts and electrical connections.

- Apply lubricant to moving parts if needed.

- Train security staff on operation and emergency overrides.

Important Notes

✔ Compliance – Ensure the turnstile meets local safety & accessibility regulations.

✔ Weatherproofing – If installed outdoors, verify IP65+ waterproof rating.

✔ Professional Help – For complex installations (networked access control), consult a technician.
